Spectra Nova JA 256_80 AAA Printhead

# Spectra Nova JA 256_80 AAA Printhead

Spectra Nova JA 256/80 AAAPrinthead
To be used with:WIT-COLOR Ultra1000-NOVA-5208, WIT-COLOR Ultra1000-NOVA-3308, DGI PS-3204D, Flora LJ 320SE, Flora HJII3200/5000SE, YISHAN PS-3204S, YISHAN POLAJET PS-3204DX, YISHAN YS5008-EE, Vutek Ultravu3360, Teckwin Teckpro S3200
Remarks:original

Description:
• The Nova JA 256/80 AAA is a compact inkjet jetting assembly designed specifically for applications using solvent, UV-curable or aqueous ink formulations at resolutions up to 450 dpi.
• Four electrically independent piezoelectric slices, each with 64 addressable channels, are combined to provide a total of 256 jets. The nozzles are arranged in a single line, at a 0.011 inch distance between nozzles.

Features:
• 75 picoliter calibrated drop size;
• Resolutions up to 450 dpi;
• 256 individually addressable, inline nozzles;
• Supports solvent, UV-curable and aqueous inks;
• Orientation independentDesigned for long service life;
• Operation up to 90ºC [194ºF];
• Dual ported for ease of flushing;
• Optional temperature control.
